Model

FusionServer 2488H V6

Form Factor

2U Rack Server

RAID Support

RAID 0, 1, 5, 50, 6, or 60; optional supercapacitor for cache power-off protection; RAID-level migration, drive roaming, self-diagnosis, and web-based remote configuration

Processors

2 or 4 x 3rd Gen Intel Xeon Scalable processors (5300/6300/8300 series), TDP up to 250 W

Memory

48 DDR4 DIMM slots, up to 3200 MT/s; up to 24 Intel Optane™ PMem modules (200 series), 2666 MT/s

Power Supply

2 hot-swappable PSUs with support for 1+1 redundancy and the following configuration options:

• 3000 W AC Titanium PSUs

2500 W (input: 200 V to 220 V AC)

2900 W (input: 220 V to 230 V AC)

3000 W (input: 230 V to 240 V AC)

• 2000 W AC Platinum PSUs

1800 W (input: 200 V to 220 V AC, or 192 V to 200 V DC)

2000 W (input: 220 V to 240 V AC, or 200 V to 288 V DC)

• 900 W AC Platinum/Titanium PSUs (input: 100 V to 240 V AC, or 192 V to 288 V DC)

• 1500 W HVDC PSUs (input: 260 V to 400 V AC)

• 1500 W 380V HVDC PSUs (input: 260 V to 400 V DC)

PCIe Expansion

Up to 11 PCIe 3.0 slots, including one dedicated PCIe slot for the OCP 3.0 NIC

Heterogeneous Accelerator Cards

2 dual-slot FHFL or 4 single-slot HHHL GPU heterogeneous accelerator cards

Security Features

Power-on password, administrator password, TCM/TPM 2.0, security front panel, and out-of-box intrusion alarm, ect.

Dimensions (H x W x D)

Chassis: 86.1 mm x 447 mm x 790 mm (3.39 in. x 17.60 in. x 31.10 in.)
